Economy CD & DVD Two Shaft Shredder

​The Economy CD and DVD Two Shaft Shredder is essential for recycling unwanted discs, which are primarily made of high-quality polycarbonate plastic.​ Every year, millions of CDs and DVDs end up in landfills or incinerators, leading to environmental harm due to their non-biodegradable materials. Proper recycling involves collecting, sorting, and shredding these discs to transform them into new raw materials for manufacturing. This process helps reduce pollution and promotes sustainable waste management.
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Product Overview

CD & DVD Two Shaft Shredder

Economy CD And DVD Two Shaft Shredder


Every year, a mass of CDs and DVDs are produced and in the meanwhile, millions of them are ended up in the landfill or incinerators. CD & DVD Recycling actually is quite necessary for environment.


Do you know what are CDs and DVDs made of? CDs and DVDs’ body is mainly made of the number 7 plastic (polycarbonate). Number 7 plastic is very high quality plastic. Many daily items can be made from this type of plastic, such as household articles, car accessories, office supplies, etc. The disc surface is with dye layer and reflective layer. The dye layer is for data storage purpose, and the reflective layer is for reflecting the light from the laser reader. The surface layer is made of certain metals.


It is not good to end up the discs in the landfills and incinerators because the materials are not biodegradable and may release harmful substance to the environment and indirectly endanger human health. Burning will also release harmful fumes to the air, resulting air pollution.choose one CD and DVD two shaft shredder seems very important.


Therefore, the best way to handle the unwanted CDs and DVDs is to recycle or reuse them. The general recycling process of these discs is to collect first, then separate and sort each disc by material types because usually each disc contains case, cover paper, and disc. Each type of these material can be recycled respectively. After sorting, you have accumulated the discs together, and then shred and reprocessed them into new raw material to reproduce new products.


Composition and Structure

CD & DVD Two Shaft Shredder

Application

CD & DVD Two Shaft Shredder

BEFORE

CD & DVD Two Shaft Shredder

AFTER

CD & DVD Two Shaft Shredder
CD & DVD Two Shaft Shredder

Technical Data Sheet

ModelMSB-E300MSB-E600MSB-E800MSB-E1000MSB-E1200
Motor Power (KW)7.5/1111/1515/30/603744/90/150
Blade Diameter (mm)∅170-300∅270-300∅270-450∅270-450∅320-520
Shaft Speed (RPM)13-18.59-3210-3210-327.5-32
Shredding Chamber Length (mm)30060080010001200
Blade MaterialGermanyGermanyGermanyGermanyGermany
Blade Thickness (mm)2020/3020/3030/4030/40
Machine Size (mm)1500×1300×18502500×1300×18502700×1300×18503300x1900x22003600×2000×2200
Machine Weight (kgs)10001500230052006400


ModelMSB-E1600MSB-E1800MSB-E2000MSB-E2200
Motor Power (KW)90180/220180/220220
Blade Diameter (mm)∅450-800∅450-800∅450-800∅450-800
Shaft Speed (RPM)5.5-14.55.5-14.55.5-14.55.5-14.5
Shredding Chamber Length (mm)1600180020002200
Blade MaterialGermanyGermanyGermanyGermany
Blade Thickness (mm)50/75/10050/75/10050/75/10050/75/100
Machine Size (mm)5500×2200×26007000×3100×40007500×3500×44008000×4000×5000
Machine Weight (kgs)30000340004000045000


Details

Detachable box

Detachable box

The shredding chamber can be disassembled from either end, allowing the main shaft to be removed by detaching the mounting plates. After disassembly, the cutter body and bearings can be inspected and replaced if needed. Properly positioning the main shaft and bearings centrally during installation is essential for maintaining structural integrity and longevity.


Heavy-load planetary reducer

Heavy-load planetary reducer

The box features a rigid casting reducer with gussets.  Its robust gear is made from high-quality steel alloy, treated with carburizing and quenching.  Precision gear grinding ensures stable power transmission, low noise, and improved carrying capacity.


Detachable cutter

Detachable cutter

The detachable blade design significantly reduces replacement time. Each crushing blade consists of three parts and can be easily replaced by loosening and retightening the bolt.


Electric system

Electric system

The electric cabinet features a Siemens/Schneider PLC and a touch screen to enhance human-machine interaction, utilizing Siemens/Schneider electrical components.


Sealing system

4.5密封系统

The bearing features a quadruple sealing design that makes it dustproof and waterproof, extending its service life and enabling excellent performance in outdoor, dusty environments.


Auxiliary system

Auxiliary system

An optional pressing device accelerates material crushing, while a rotating screen ensures dimensional uniformity of the crushed products.


Splined main shaft

Splined main shaft

The moving blade base and main shaft are aligned using spline transmission, featuring a large surface junction to prevent stress concentration. The spiral design enhances crushing efficiency and reduces energy consumption. The moving blade base undergoes 100% ultrasonic and non-destructive inspection to maximize the cutter's crushing capacity.


Heavy-load self-aligning bearing

Heavy-load self-aligning bearing

Heavy-load self-aligning bearings are installed on both main shafts to absorb impact forces when blades experience heavy loads.  ENERPAT shredders use top brands like FAG and SKF as standard bearing configurations.
